Feature

Paragon 1x16 Mini Prism Scope

· Crystal-Clear Optics: Fully Multi-Coated Lens Delivers Sharp, Distortion-Free Image Quality

· True 1x with Wide FOV: 14.5° Field of View Enables Two-Eyes-Open Shooting and Full Situational Awareness

· Flexible Eye Relief: 3.0in / 76mm Eye Relief with Large Eye Box for Quick and Comfortable Targeting

· Compact & Cartridge-Optimized: Just 75mm Long, Designed for .223 / 5.56x45mm Platforms

· Fast and Precise Reticle: 2MOA Center Dot with Ring, 1MOA Adjustments, Supports Absolute Co-Witness

· Battle-Ready Build: IP67 Waterproof with Rugged 6061-T6 Aluminum Housing for Tough Field Use

Paragon Mini Magnifier

Compact Precision Design: Present Excellent Image, Mini Size, Adjustable Windage & Elevation, with Riser Section

Comfortable Shooting Position: 67mm (2.6in) Long Eye Relief Ensures Flexible and Fatigue-Free Shooting

Paragon 3x Magnifier

Mini Size, Adjustable Windage & Elevation, with Riser Section

66 mm / 2.6 in Long Eye Relief for Comfortable Shooting Position

Build-in Flip-to-Side Picatinny Mount 36 mm / 1.4 in from Bottom to Sight Center

Paragon 5x Magnifer

Present Excellent Image, Mini Size, Adjustable Windage & Elevation, with Riser Section

67 mm / 2.6 in Long Eye Relief for Comfortable Shooting Position

Build-in Flip-to-Side Picatinny QD Mount 36 mm / 1.4 in from Bottom to Sight Center

What is a prism scope?

A prismatic scope is a type of optical sight that uses a prism to reflect and refract light, rather than a traditional lens system.

The prism inside the scope is used to bend the light, allowing for a more compact and lightweight design than traditional scopes.

Prismatic scopes are often used in firearms, where they provide a clear and accurate image of the target while minimizing the weight and bulk of the optics. The Paragon 1x16 mini prism sight is particularly compact, with a true 1x image that enables ultra-fast shooting.

Specification

Paragon 1x16 Mini Prism Scope

• Magnification: 1x
• Objective Lens: 16mm
• Exit Pupil: 15mm
• Optical Coating: Fully multi coated
• Field of View: 14.5°
• Field of View: 25.4m @ 100 meters
• Field of View: 76.3ft @ 100 yards
• Eye Relief: 76mm / 3.0in
• Click Value: 1MOA
• Elevation Range: >40MOA
• Windage Range: >40MOA
• Height: 36mm (1.41") from bottom to center
• Length: 75mm / 3.0in
• Weight (net): 230g / 8.1oz without mount
• Reticle: Etched glass VEP-CDR
• Parallax Setting: 100 yards
• Finish: Black matte
• Illumination: 10 levels red
• Battery Type: CR2032
• Shock proof and fog proof (nitrogen filled)
• High quality aluminum alloy in durable black matte finish
• Fast focus eyepiece at ocular lens adjustment -2 to 2
• 21mm picatinny mount
• Accessories includes: riser section, plastic wrench, hex key and cleaning cloth etc

Paragon 3x18 Mini Magnifier

• Magnification: 3x
• Objective Lens Dia: 18mm
• Exit Pupil: 6.0mm / 0.24in
• Length: 70mm (2.75in)
• Height: 36mm (1.4 inch, from the base to the optics center)
• Weight (net): 215g (7.6oz)
• Eye Relief: 67mm (2.6 Inch)
• Field of View: 7.4°
• Optics Coating: Fully multi coated
• Shock proof that is designed for real fire caliber
• Windage and elevation can be adjusted
• Aluminum alloy 6061-T6 in black matte body
• Flip-to-Side Quick Release picatinny mount
• Fast focus eyepiece at ocular lens adjustment from -2 to 2
• IP67 water proof in 1 meter depth water for 30 minutes
• With riser section, user manual, cleaning cloth and hex key etc

Paragon 5x30 Mini Magnifier

• Magnification: 5x
• Objective Lens Dia: 30mm
• Exit Pupil: 6.0mm / 0.24in
• Length: 94mm (3.7in)
• Height: 36mm (1.4 inch, from the base to the optics center)
• Weight (net): 250g (8.8oz)
• Eye Relief: 67mm (2.6in)
• Field of View: 4.4°
• Optics Coating: Fully multi coated
• Shock proof that is designed for real fire caliber
• Windage and elevation can be adjusted
• Aluminum alloy 6061-T6 in black matte body
• Flip-to-Side Quick Release picatinny mount
• Fast focus eyepiece at ocular lens adjustment from -2 to 2
• IP67 water proof in 1 meter depth water for 30 minutes
• With riser section, user manual, cleaning cloth and hex key etc
